Viega test plugs: When it comes to carrying out a pressure
test in unfinished installations, a partial installation can be
sealed off using the pressure test plug. In addition, it also
allows a partial installation to be put into operation for a
limited period of time.
Pressure test plugs
Quick leakage checks made easy: the pressure test plugs from Viega help to check sections
of pipe-work effortlessly – and being reusable, they are a highly effective and cost efficient
solution. The alternative would be to use permanent end caps which would be cut out and
thrown away after testing. That’s both time consuming and expensive. The bronze test plugs
from Viega can be reused thousands of times. They come in a range of dimensions from
DN15 to DN50 and have a pressure rating of 1600 kPa max. They also have an integrated
valve for bleeding lines. The test plugs can be used with all Viega Propress fittings. They are
designed to be inserted into an un-pressed Propress fitting end for pressure testing and can
then be removed after testing, leaving the Propress end usable for a final press connection.
Viega. A better idea!
Designed to save time and money
Viega test plugs
viega.com.au
